Horizontal dark ultra quiet installed central Air Conditioner fan coi units

Good quality HCFC Refrigerants for sales
Good quality HCFC Refrigerants for sales
service is good and refrigerant 22 & 134's price are ok

—— Leonardo

I'm Online Chat Now

Horizontal dark ultra quiet installed central Air Conditioner fan coi units

China Horizontal dark ultra quiet installed central Air Conditioner fan coi units supplier

Large Image :  Horizontal dark ultra quiet installed central Air Conditioner fan coi units

Product Details:

Place of Origin: CHINA
Brand Name: AUX
Certification: TUV QEC UKAS OHSAS CNAS S CE ICP ISO9001 CCC CRAA
Model Number: FP-34WA FP-51WA FP-68WA FP-85WA FP-102WA FP-136WA FP-170WA FP-204WA FP-238WA

Payment & Shipping Terms:

Minimum Order Quantity: 1TABLE
Price: USD80-200
Packaging Details: CARTONS
Delivery Time: 3-15DAYS
Supply Ability: 10000TABLE 15DAYS
Contact Now
Detailed Product Description
FP-34: Air Volumem 340 3/h);Rated Cooling Capacity1.8(kW);Rated Heating Capacity2.7(kW) FP-51: Air Volumem 510m3/h);Rated Cooling Capacity2.7(kW);Rated Heating Capacity4.05(kW)
FP-68: Air Volumem 680m3/h);Rated Cooling Capacity3.6(kW);Rated Heating Capacity5.4(kW) FP-85: Air Volumem 850m3/h);Rated Cooling Capacity4.5(kW);Rated Heating Capacity6.75kW)
FP-102: Air Volumem 1020m3/h);Rated Cooling Capacity5.4(kW);Rated Heating Capacity8.1(kW) FP-136: Air Volumem 360m3/h);Rated Cooling Capacity7.2(kW);Rated Heating Capacity10.8(kW)
FP-170: Air Volumem 1700m3/h);Rated Cooling Capacity9(kW);Rated Heating Capacity13.5(kW) FP-204: Air Volumem 2040m3/h);Rated Cooling Capacity10.8(kW);Rated Heating Capacity16.2(kW)
FP-238: Air Volumem 2380m3/h);Rated Cooling Capacity12.6(kW);Rated Heating Capacity18.9(kW)

FP -explosion-proof fan coil manufacturers supply Horizontal dark ultra-quiet installed central air-conditioning fan coil units

Horizontal dark ultra quiet installed central Air Conditioner fan coi units

Fan coil unit is mainly composed of low noise motor, fin and heat exchange coil, etc.Dish tube cold (hot) media by computer room air conditioning centralized water supply.Fan coil product standards must be based on GB/T 19232-2003 production of fan coil units, the national air conditioning equipment quality supervision and inspection center for many times entrusted by the state administration of quality supervision, inspection and quarantine national fan coil units of product quality supervision and spot check, fan coil to detect unqualified project is mainly in the majority with noise and refrigerating capacity.
Fan coil is an ideal product, at the end of the central air conditioning fan coil units are widely used in hotels, office buildings, hospitals, residential and commercial, scientific research institutions.According to understand, to meet the different occasions of design selection, fan coil type are very diverse, horizontal dark back (bellows) installed fan coil units, horizontal surface mounted fan coil units, vertical dark outfit fan coil, vertical with the fan coil, cassette two wind fan coil, sovereigns cassette fan coil units and wind wall fan coil, etc.


Fan coil units as the end of the central air conditioning equipment, its quality decides the effect of indoor air conditioning.At the same time, the cleaning problem has a direct impact on the central air conditioning use effect.Dust particles from the atmosphere, under the effect of long-term smoking, return air, the air blower of aluminum fin dust dirt, at that moment, on the one hand affect the chilled water and hot air heat makes the air temperature drops affected;On the other hand are cooled after heat exchange is also influenced by the cold air is sent out, due to open the air conditioning room is still not cold phenomenon.After cooling for central air conditioning host send 7 degrees of water to fan coil units, fan coil in exchange became 15-16 degrees after the cold wind, so that reduce the room temperature.So, central air conditioning in use after a period of time, must be aluminum fin cleaning of the fan in order to solve these problems.
At present, the traditional commercial central air-conditioning fan coil market share tends to stabilize, in which enterprises want to develop a new situation, has been very difficult.In the face of fierce market competition, many central air-conditioning fan coil companies open up market segment, to avoid the confrontation with the traditional, rail transit field become blue ocean central air conditioning enterprise competition in the market.



Model Air Volumem3/h) Rated Cooling Capacity
(kW)
Rated Heating Capacity
(kW)
FP-34 340 1.80 2.70
FP-51 510 2.70 4.05
FP-68 680 3.60 5.40
FP-85 850 4.50 6.75
FP-102 1020 5.40 8.10
FP-136 1360 7.20 10.80
FP-170 1700 9.00 13.50
FP-204 2040 10.80 16.20
FP-238 2380 12.60 18.90
